Product Introduction:
1. Computer optimized structure design, three-beam four-post structure,simple, economical and practical. 2. Hydraulic control cartridge valve integrated system reliability, long life andsmall hydraulic impact, reducing the link pipe and leak points. 3. Independent electrical control system working reliably. Action andintuitive. Easy maintenance. 4. Use the button centralized control, with adjustment for manual and semi-automatic operation. 5.Via the operator panel to choose from. Can be achieved given away twoconstant pressure forming process, and has features such as securityduring rolling. 6. Slider working pressure load and slow down quickly work into the travelrange can be adjusted according to process requirements.
Optional Configuration
1. Blanking damping device
2. Screen safety protection device
3. Touch screen type industry
4. Rapid mold clamping device
5. Mobile working platform
6. Oil cooling device
7. Ramming device
8. Die change with floating guide rail and a rolling bracket
9. Slider locking mechanis
Specification
Unit
63T
100TA
100TB
100TC
160TA
160TB
200TA
Nominal pressure
KN
630
1000
1000
1000
1600
1600
2000
Max working pressure of liquid
Mpa
25
25
25
25
25
25
25
Oil cylinder range
mm
260
300
300
300
300
500
400
The largest open size
mm
500
600
600
540
480
800
800
Effective area of the workbench
mm
580
640
700
800
640
800
800
mm
500
560
700
800
550
800
800
Bench height
mm
580
700
700
700
750
766
685
Floor area
mm
1700*900
1800*850
190*850
2000*1000
1900*850
2200*1100
2200*1100
Machine Height
mm
4850
2300
2300
2515
2500
2800
2835
Forward speed
mm/s
26
80
80
80
80
100
100
Working speed
mm/s
15-20
10-17
10-17
10-17
12-18
12-18
8-13.5
Return rate
mm/s
57
64
64
64
64
64
72
Motor Power
KW
5.5
5.5
5.5
5.5
7.5
7.5
7.5
Pressure of top cylinder
KN
200
200
200
400
400
400
Route of below cylinder
mm
200
200
200
200
200
200
